The Default Video output is 1080P AHD Mode, compatible with all DVRs by switching to video output mode. Starvis 2MP 1080P Analog Camera 4 in 1 Mini HD Camera Covert Camera... It does not support IP NVR. 2. In TVI, CVI, AHD DVR Mode, camera resolution is 1080P. Video Mode must be switched according to your 1080P DVR type. Please make sure your DVR supports 1080P TVI/CVI/AHD signal input otherwise switch camera to Analog. 4. If need to remote view by App, customer needs to use the APP of DVR Technical Parameters: - 1/2.9 CMOS sensor - Resolution: 1920x1080 - 65ft IR Range - TV System: NTSC - Video Output: HD-TVI(1080P),(AHD/TVI/CVI/CVBS) - Day &Night: Support (ICR) - Frame Rate: 25fps (50HZ), 30fps (60Hz) - Min illumination: 0.1lux(LED ON) 0.01lux(0-3 lux LED) - S/N Ratio: 52dB (AGC off) - Electronic Shutter: Auto 1/50s (1/60s)-1/100.000s - White Balance: Auto - Gain Control: Auto - Weatherproof for indoor/outdoor - Power Supply:DC12V 1000mA 4 in 1 video model, provides flexible for your security applications HD-TVI/ CVI/AHD/960H technology delivers zero latency HD video over RG59 coax or any standard analog CCTV cabling up to 1600’. Package included: 1 x Dome camera 1 x Bag of mounting screws 1 x Installing Template 1 x Manual DIP Switch – Easy switch of your camera video output format (TVI/CVI/AHD/CVBS). With convenient DIP Switch control of settings over coax cabling, you can eliminate the need for a separate cable. Default mode is HD AHD, if you are using other type of DVR, like Analog DVR, please switch the video type follow the user manuals. This camera is 2 Megapixels high definition 1080p HD TVI/AHD/CVI/960H(1000 TVL), 65ft IR night vision range. It has a 2.8mm Fixed lens with 100 degrees wide Field of View (FOV) to cover large areas If connect to 720P DVR or 960H DVRS, it won’t work. You must know before you buy: 1. This 4-in-1 security camera requires a DVR for recording video. 04433-10051-71: Toyota Forklift SEAL KIT - STEER CYLINDER Video mode can be switched based on the DVR video mode. LONNKY Full HD 1080P 2MP Indoor/Outdoor Bullet Camera This BNC security camera can work indoors and outdoors, come with IP66 weather-rated metal housing, and operating temperature is -40°F ~ 140°F. Cctv Camera Security System Real HD 2MP 1080P Analog Camera For Existing Coax Analog Dvr System 65ft Ir Night Vision 36mm Lens Outdoor Compatible With 1080p Hikvision Dahua Lorex Amcrest Dvr Hilook Camera
