Compact & Lightweight: Easily integrates into custom electrical systems. DaierTek UP Down Momentary Reverse Polarity Switch 12V30A DPDT Polarity Reversing Switch RV Power Jack Switch for 5th Wheel Tongue Trailer Stabilizer. About this item Polarity Reversing-This 3 way dpdt switch is polarity reversing switch , with two jump bar to help you easily reverse the direction of current by pressing the switch to different... Its momentary action (ON)-OFF-(ON) ensures safe, automatic reset to the OFF position, while the included waterproof cap protects it from harsh outdoor elements. Measuring just 0.62 x 0.39 x 1.14, this compact switch includes jumper wires for easy installation. Certifications TUV Certified CE Certified CQC Certified Applications RV Power Tongue Jacks Trailer Motor Control DC Motor Polarity Reversal Custom Electrical Systems Stabilizers and Lifting Mechanisms Enhance your electrical systems with this high-performance reverse polarity toggle switch today. Robust Durability: Tested for over 10,000 mechanical and electrical cycles. ⚙️ HIGH-QUALITY SPECIFICATIONS Supports 30A at 12V DC or 15A at 250V AC, featuring silver contacts for efficient, low-resistance switching. Specifications Parameter Details Model Number KN3C-223AAP Switch Type Momentary Reverse Polarity Toggle Switch Function (ON)-OFF-(ON) Contact Type Double Pole Double Throw (DPDT) Voltage Rating 12V DC / 250V AC Current Rating 30A @ 12V DC / 15A @ 250V AC Pin Configuration 4 Pins with Jumper Wires Included Material Silver Contacts, Durable Plastic Housing Waterproof Cap Yes, Included Operating Temperature -25°C to +85°C Contact Resistance ≤50mΩ Insulation Resistance ≥1000MΩ @ 500V DC Dielectric Strength 1500V AC for 1 Minute Mechanical Life ≥10,000 Cycles Electrical Life ≥10,000 Cycles Dimensions Parameter Measurement Switch Body Size 15.7 x 10 x 28.9 mm (0.62 x 0.39 x 1.14) Wire Length 21.2 cm (8.3) Packaging Dimensions 18 x 16 x 8 cm Net Weight 50 g Features Momentary Action: (ON)-OFF-(ON) functionality ensures safe and efficient polarity reversing. High Performance: Silver contacts minimize resistance and provide smooth operation. Weatherproof Design: Includes a waterproof cap for outdoor use. With a temperature range of -25°C to +85°C, it performs reliably in any climate. This 12V 30A DPDT 4-Pin Toggle Switch is designed for heavy-duty applications, making it the ideal choice for RV jacks, trailer power tongue jacks, and DC motor reversing. JOINPAYA Miniature Dollhouse Bedding Set : Pink Dolls Pillow Mattress Comforter Cute Kit Doll Bed Sheets Dollhouse Bedroom Accessories For 9-12in Doll £926 Save 8% with voucher FREE delivery Tomorrow, 21 Dec on your first eligible order to UK or Ireland 🛠️ EASY INSTALLATION Equipped with 4 pins, included jumper wires, and a compact design for effortless integration into RVs, trailers, and custom electrical projects. The Secret to aking Boat Trailers Run Soothly? It's All in the Winch 🌧️ WEATHERPROOF DESIGN Comes with a waterproof cap to shield the toggle from water and dust, ensuring durability in harsh outdoor environments. Toggle Switch 12v Momentary Reverse Polarity Switch 12V 30A | DPDT 4-Pin (ON)-Off-(ON) Toggle Switch With Waterproof Cap | Motor Control Switch For Rv Jack Switch
