The unit comes with a zippered vinyl carrying case, a plastic transfer pipet and an instruction manual. Specifications Measurement scale range Brix 0.0 to 15.0% Specimen measurement temperature range 10 to 30 degrees Accuracy Brix + or - 0.1%, Temperature + or - 1 degrees C Resolution Brix 0.1%, Temperature 1 degrees C Ambient temperature for unit operation 10 to 30 degrees C Sample volume 0.1ml Measurement time Instantaneous Body type Copper alloy with a nickel-chrome coating Illumination Ambient light; unit requires no additional power source Dimensions 40 x 40 x 185mm (H x W x D) Weight 285g Warranty One year H is height, the vertical distance from the lowest to highest point; W is width, the horizontal distance from left to right; D is depth, the horizontal distance from front to back. What’s in the Box? BTX-20 refractometer Vinyl carrying case Plastic transfer pipet Instructions In-process refractometers are used for continuous process monitoring and data readouts, and are generally fitted into a piping system for ongoing analysis. Calibration can be controlled and adjusted with a tool-free calibration ring and a set screw. The outer shell is rubber coated with dimpled grip for easy gripping and the rubber coating guards against hand heat for accurate measurements. Refractometers - Lab Equipment & Instrumentation - Products Benchtop refractometers typically measure with a higher degree of accuracy than handheld units. Automatic temperature compensation (ATC) for immediate and accurate calibration readings, regardless of ambient temperature A Brix refractometer measures the refractive index of a solution in a sample, converts it to sugar concentration in units of percent by weight (% Brix, also known as degrees Brix), and displays the results. The unit is factory-calibrated and can be calibrated with distilled water. VEE GEE Scientific manufactures laboratory equipment and supplies, and makes the VanGuard brand of products. The company, founded in 1981 and headquartered in Kirkland, WA, offers scientific equipment for educational, research, clinical, and industrial applications. Automatic Transmission Oil Cooler Hose Assembly - Part Number 624-334 (624334) by Dorman. Location: Outlet from Radiator. Upper. Finish: Natural. Available in Parts A non-roll stand prevents the unit from rolling when placed on a flat surface such as a table or bench top. The analog Brix scale features a bright, high-contrast display for clear visibility of the boundary and memory lines intersection. Refractometers measure the refractive index of a substance, which is its optical characteristic, and the number of dissolved particles in it. Refractometers can work with natural light, or with an external power source such as batteries or electricity. The VEE GEE BTX-20 features ATC for immediate, accurate readings, with an ambient temperature of 10 to 30 degrees C. Digital handheld models provide a digital readout. Handheld refractometers are elongated and telescope-shaped, or shorter and rectangular. Some analog-display refractometers can be used for both solids and liquids. Salinity Refractometer 0-90% Handheld Refractometer Brix Scale Honey Sugar Content Sugar Food Digital Refractometer Optical glass prism mounted in all-metal housing for quick temperature equilibrium between sample and prism PORTABLE DIGITAL REFRACTOMETER BRIX SCALE (0-50%) FOR COLOSTRUM... The VEE GEE BTX-20 is a handheld, portable, water-resistant sugar refractometer with a Brix scale that measures in the 0.0 to 32.0% range, is powered by ambient light, has automatic temperature compensation (ATC), an optical glass prism, and a durable metal body with rubber grip. Analog handheld refractometer readings are obtained by looking through the monocular eyepiece and viewing where the boundary line intersects with the memory line. The refractive index is the ratio of the speed of light in empty space to the speed of light in a substance; when light passes from one medium to another. This refractometer is housed in a durable metal body. Durable metal and rubber outer shell with a telescope-shaped, streamlined design (40 x 40 x 185mm), a rubber grip to guard against hand heat for accurate measurements, and a non-roll stand to protect against damage Digital-display refractometers are used exclusively for liquids.
