Step-by-step guide to wiring a boat lift with diagrams The wiring diagram is provided as a reference for most installations. Schlage Commercial 626 10-072 L-Series Strike, Satin Chrome , mortise lock strike. Made for Schlage L Series Mortise Locks with Deadbolt and Latch Boat Motors Enclosed Boat Lift Switch Single Phase / Three Small Electric Boat MOMENTARY SWITCH: (spring action) only engages while the user is pushing the handle. Condition: * New Surplus Stock, In OEM Packaging. As Pictured.. Additional Notes: * Momentary Switch is actuated only when pressing handle, switch will return to off position when handle is released. * For Motors 1.5 HP at 120 Volt AC or 2 HP at 240 Volt AC * Mount Vertical or Horizontal * Enclosure is IP65 Rated ASI P0202500S -RH-EKIT This switch features self-cleaning contacts, silver alloy plating, and a UL94V0 thermoplastic housing. This P0202500S-RH-EKIT single-phase drum switch enclosed in a high impact thermoplastic enclosure. Highly visible red handle with enclosure that is IP65 rated. A UL508 listing of 600 Vac, 20A this forward and reverse motor switch is ideal for single-phase motors ranging from 0.5 HP to 1.5HP for a 120 Vac motor and from 1 to 2 HP for a 240 motor. The MOMENTARY SWITCH only engages while the user is activating the handle and will spring to the off position when handle is released. WIRING: Please refer to your motors wiring instructions on how to wire switch Max 1.5 HP at 120Vac Motors or Max 2 HP at 240Vac Motors Please refer to your motor's manual for wiring directions or contact a certified electrician.
